1600mm automatic  slitting machine with laminating function

Automatic Slitting Machine with Laminating Function, Good Price



Product Description



Model

HX-1300FQ

HX-1600FQ

Max feeding Width

1300mm

1600mm

Main Engineer Power

4kw

6kw

Speed

80m/min

80m/min

Size

2400*2000*1300mm

2400*2300*1600mm

Weight

1200kg

1500kg

Unwinding Diameter

600mm

800mm

Winding Diameter

450mm

450mm

Precision

±0.1mm

±0.1mm

Power

380v 50hz

380v 50hz





This is the finishing equipment. It is suitable for slitting roll/reel material such as paper, foil,

adhesive labels. It has functions of meter counter,

piece counter, length and quantity setting, automatically stopping, After reaching a preset number or

running meters .web guiding system and so on. This robust machine consisting of a solid steel frame,The structure is compact , fast, with high efficiency, easy and steady operation.





1.Machine frame made of coated steel

2.Electronics integrated in the machine frame

3.unwinding with pneumatic compressed shaft for 3" cores

4.rewinding with pneumatic compressed shaft for 3" cores

5.Web tension adjustable via magnetic powder clutch

6.Axial fan for suction of waste strip

7. The minimum slitting width is 8mm

8.Imported gas sensitive device is adopted to detect the rectification of rolling, with fully automatic

hydraulic rectification control.

9.Laminating and slitting can be done at one time or separately.




Standard configuration



1.one slitting station

2.One laminating station

3.With one piece 3'' unwinding shaft,2 pieces rewinding shafts

4.With meter/number counter

5.With two photoelectric eyes

6.With 8 pieces round slitting knives

7.Machine has blower fan to blow away the trimmed edge

Application

1. It is applicable for the slitting tooling of industrial adhesive tape, electronic material, protective film, copper foil, aluminum foil, OPP, PE, PVC, sheet, cloth, etc.
2. This machine is widely used in the industries such as printing, packing, electronics, leather, clothes making, plastic, etc.

Samples Show

Automatic Slitting Machine with Laminating Function, Good Price

Automatic Slitting Machine with Laminating Function, Good Price
Automatic Slitting Machine with Laminating Function, Good PriceAutomatic Slitting Machine with Laminating Function, Good PriceAutomatic Slitting Machine with Laminating Function, Good Price

This machine applys to a variety of  materials , includes but not limited to above .

If you are not sure whether this machine could be suitable for your material ,please inquiry us .





Packaging & Shipping

The package for machine is plywood case .it's strong enough to prevent from damage when transporation .

Our machines have been exported to more than 40 countries .We have agent in South Korea .
