JPS320-5C Automatic Five Color Laminating Rotary Die Cutting Machine Printing Machine For Self-adhesive Film Label Sticker Roll

Characteristic:

1. Adopt the ceramic anilox roller to spread ink.
2. Unwinding and rewinding are controlled by magnetism power brake, clutch. (or by automatic tension controller of Mitsubishi , made in Japan).
3. Printing unit adopt 360º for registration.
4. Printing unit have one infrared to dry the device group each.
5. The rubber roller can break away from automatically while parking, and running at a low speed, in order to avoid water being black to be dry.
6. The main motor is adopted the import stepless regulation of frequency conversion.
7. Unwinding, printing, varnishing, IR drying, laminating and rewinding can be finished in one process
8.This kind of printing machine is best for each printing companies to print on adhesive-paper labels and other commercial label.


Optional configuration:

1. web guiding
2. plate mounting with microcomputer display screen
3. computer monitor
4. turn bar
5. slitting station
6. rotary die cutting station
7. laminating
8. UV dryer
9. Corona treatment
10. Cold foil


After-service:

1. Warranty for machine: 12months
2. After-service: A reply within 24 hours
3. A free training in our factory available before delivering machines


Printing samples:

Five Color Laminating Rotary Die Cutting Machine Printing Machine for Self-Adhesive Film Label Sticker Roll



Technical Parameters:
           Model
Specification
JPS320-5C
Printing speed (m/min)60
Printing color (colors)5
Max. paper width (mm)330
Max. printing width (mm)320
Max. Unwinding diameter (mm)600
Max. rewinding diameter (mm)600
Printing perimeter (mm)175-380
Registration accuracy(mm)±0.1
Voltage (v)380±10%
Total power9kw
Weight of machine (kg)2200/2400
Dimension (mm)2500*1100*2600


Standard configurations:
Standard configurations Option
5×ceramic anilox roller AC contactor Corona treatment
10×printing roller Variable frequency Plate mounting
Magnetic powder brake Push buttonVideo system
Magnetic particle clutch Control panel Web guide
1×Unwinding tension controller Hall switch Lamination unit
1×Rewinding tension controllerMain motor Rotary die cutting unit
5×Infrared dryer  2×shaft  Dividing cutting device
5×ink roller   a turn barUV dryer
Breaker   A lamination station Cold foil
Temperature control A rotary die cutting station





JPS320-5C Machine Version

Five Color Laminating Rotary Die Cutting Machine Printing Machine for Self-Adhesive Film Label Sticker Roll




JPS320-5C Machine Configuration

Five Color Laminating Rotary Die Cutting Machine Printing Machine for Self-Adhesive Film Label Sticker Roll





JPS Factory Show
Five Color Laminating Rotary Die Cutting Machine Printing Machine for Self-Adhesive Film Label Sticker Roll



JPS320-5C Machine Application
Five Color Laminating Rotary Die Cutting Machine Printing Machine for Self-Adhesive Film Label Sticker Roll
